excessive play/ slop at the u-joint

Post by bobt » Sun May 24, 2020 6:39 pm

I've been working on oil leaks on my 1915 touring. Today I drove around with the floorboards off and noticed excessive movement at the u-joint connection (I call it a ball and socket) do I need to add the aftermarket shim? Can I adjust the radius rods to help this? Thanks, bobt

User avatar

RajoRacer
Posts: 1274
Joined: Sun Jan 06, 2019 12:18 pm
First Name: Steve
Last Name: Tomaso
Location: Longbranch, WA
MTFCA Number: 14972
MTFCI Number: 15411
Board Member Since: 2001

Re: excessive play/ slop at the u-joint

Post by RajoRacer » Sun May 24, 2020 7:12 pm

Install a shim - the torque tube ball has excessive wear.


Topic author
bobt
Posts: 32
Joined: Tue Aug 13, 2019 5:43 am
First Name: Robert
Last Name: Thompson
Location: virginia

Re: excessive play/ slop at the u-joint

Post by bobt » Sun May 24, 2020 7:34 pm

No gasket. Correct? bobt


Jerry VanOoteghem
Posts: 263
Joined: Sun Jan 06, 2019 4:06 pm
First Name: Jerry
Last Name: VanOoteghem
Location: S.E. Michigan

Re: excessive play/ slop at the u-joint

Post by Jerry VanOoteghem » Sun May 24, 2020 7:44 pm

bobt wrote:
Sun May 24, 2020 7:34 pm
No gasket. Correct? bobt
No gasket between the retaining ring and the ball, but there is a gasket between the 4th main and the hogshead.

Yup, you can put a shim between the ring and the ball. Be sure it doesn't bind when you're done.
