Brass Magnets Clamping Screws

Post by AndreFordT » Mon Jul 13, 2020 12:12 am

Good morning All,

I am working on a 1912 engine and should like to clean up the brass magnet clamping screw thread in the flywheel.
As I was looking for a tap to do this at my usual dealer and couldn't find it . The 14/24 tap or the 1/4-24 tap was unknow.
Where can I find this? (I am living in Belgium)
What does it mean 14/24? Is 24 the number of threads on one inch? Where stands the 14 for?

Thanks
Andre
Belgium


lmitch
Posts: 52
Joined: Sun Jan 06, 2019 4:11 pm
First Name: Lee
Last Name: Mitchell
Location: Atlanta

Re: Brass Magnets Clamping Screws

Post by lmitch » Mon Jul 13, 2020 12:19 am

1/4 - 24 = One Quarter Inch Diameter 24 Threads Per Inch = .250 inch diameter 24 TPI

User avatar

Squirrel
Posts: 106
Joined: Sat May 30, 2020 9:54 pm
First Name: Jim
Last Name: Forbes
Location: Sierra Vista AZ
Board Member Since: 2020

Re: Brass Magnets Clamping Screws

Post by Squirrel » Mon Jul 13, 2020 12:36 am

14 is a screw size. It is not often used in modern times, as a machine screw. Machine screws up to size 10 are still common in the US.

24 is the number of threads per inch.

https://www.mscdirect.com/product/details/04439451

There is also a machine screw size of 1/4, which is one quarter inch outside diameter. They are different.


Dan Hatch
Posts: 955
Joined: Tue Jan 08, 2019 7:31 pm
First Name: Dan
Last Name: Hatch
Location: Alabama
MTFCA Number: 49974

Re: Brass Magnets Clamping Screws

Post by Dan Hatch » Mon Jul 13, 2020 12:39 am

Which one are you needing? Old ring gear on a new repro. Email me I can hook you up. Dan

User avatar

Topic author
AndreFordT
Posts: 205
Joined: Sun Jan 06, 2019 12:25 pm
First Name: Andre
Last Name: Valkenaers
Location: Scherpenheuvel
MTFCA Number: 23792
MTFCI Number: 19330

Re: Brass Magnets Clamping Screws

Post by AndreFordT » Mon Jul 13, 2020 7:47 am

Dan,
I just send you a Email
Andre
Belgium

User avatar

DanTreace
Posts: 1314
Joined: Sun Jan 06, 2019 10:56 am
First Name: Dan
Last Name: Treace
Location: North Central FL
MTFCA Number: 4838
MTFCI Number: 115
Contact:

Re: Brass Magnets Clamping Screws

Post by DanTreace » Mon Jul 13, 2020 8:24 am

Good of Dan Hatch to fix you up with the correct tap.

The brass screws are made of an obsolete thread type, so uncommon to have easy sources to find one.


Later mfg. of reproduction ring gears got the thread i.d. wrong and used modern 1/4" x 24 tpi. So you have to know early flywheel without gear or original ring gear being reused, use the #14 x 24.

If new reproduction ring gear, use 1/4" x 24.
The best way is always the simplest. The attics of the world are cluttered up with complicated failures. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford

User avatar

Susanne
Posts: 355
Joined: Sat Apr 13, 2019 6:06 pm
First Name: Susanne
Last Name: Rohner
Location: Northeastern California
MTFCA Number: 464
MTFCA Life Member: YES
Board Member Since: 1999
Contact:

Re: Brass Magnets Clamping Screws

Post by Susanne » Mon Jul 13, 2020 11:42 am

And they are close - a #14 screw is .242" (or 6.145 mm), 1/4 is .250 (6.35 mm). Just enough to get you in trouble!
