brake lever gets stuck when put forward
when i Put the brake lever all the way forward it gets stuck and will not come back until I move the lever on the trans up were it rides on the cam by the trans what do I need to adjust to fix this thanks mike
-
speedytinc
- Posts: 4725
- Joined: Fri Feb 12, 2021 12:24 pm
- First Name: john
- Last Name: karvaly
- * REQUIRED* Type and Year of Model Ts owned: 14/15 wide track roadster. 23 touring, 27 roadster pickup, 20ish rajo touring
- Location: orange, ca
- Board Member Since: 2020
Re: brake lever gets stuck when put forward
Get out your service manual. Check your low pedal link & cam contact bolt.
-
Jerry VanOoteghem
- Posts: 4082
- Joined: Sun Jan 06, 2019 4:06 pm
- First Name: Jerry
- Last Name: Van
- Location: S.E. Michigan
Re: brake lever gets stuck when put forward
Post a picture of the cam and how the adjustment bolt interferes with its movement.
Could be that your cam is worn so bad that the adjuster bolt can't slide over it.
Could also be that the adjuster bolt is way too far extended, such that it snags on the cam.
Might help if your adjuster bolt was turned upside down, so the bolt head rides on the cam instead of the bolt end.
Or ???
Need pics...
Could be that your cam is worn so bad that the adjuster bolt can't slide over it.
Could also be that the adjuster bolt is way too far extended, such that it snags on the cam.
Might help if your adjuster bolt was turned upside down, so the bolt head rides on the cam instead of the bolt end.
Or ???
Need pics...
-
TRDxB2
- Posts: 6262
- Joined: Tue Jan 08, 2019 4:56 pm
- First Name: Frank
- Last Name: Brandi
- * REQUIRED* Type and Year of Model Ts owned: Speedsters (1919 w 1926 upgrades), 1926 (Ricardo Head)
- Location: Moline IL
- Board Member Since: 2018
Re: brake lever gets stuck when put forward
check it out. Picture of where it get stuck would be best
- Attachments
-
