15 Touring
I am working on a 15 touring and I have a question about the windshield frame. The swivel bolt on my frame has a round head with no slot and goes inward with a nut on the inside, others I have seen have the head of the bolt on the inside and a nut on the outside. I have two windshield frames and one swivel bolt has a slot for a flat screw driver also with the nut on the inside. What is correct?
-
KWTownsend
- Posts: 1429
- Joined: Mon Jan 07, 2019 6:51 pm
- First Name: Keith
- Last Name: Townsend
- * REQUIRED* Type and Year of Model Ts owned: late 1911 touring, 1915 runabout, 1919 touring, brass speedster
- Location: Gresham, Orygun
- MTFCA Life Member: YES
- Board Member Since: 1999
Re: 15 Touring
Round bolt with slot goes on the inside with springs. The nut goes on the outside along with the loop for top hook and cotter pin.
Sometimes windshield hinge parts get mis-matched.
Sometimes windshield hinge parts get mis-matched.
-
Jerry VanOoteghem
- Posts: 4199
- Joined: Sun Jan 06, 2019 4:06 pm
- First Name: Jerry
- Last Name: Van
- Location: S.E. Michigan
Re: 15 Touring
Keith is definitely correct about the bolt/nut orientation, however, after snagging my hand on the castle nut and cotter pin too many times, I reversed it and put the nut on the inside.
