Engine CAD files?

Post by JBog » Sat Nov 08, 2025 9:22 pm

Does anyone have CAD files of the T engine and its associated parts? I am interested in making a 3D printed replica (not life size, much smaller); mainly for educational purposes. I like the idea of being able to have a little plastic engine that functions a little bit for demonstration purposes.
Top

Mike Silbert
Posts: 114
Joined: Sat Feb 08, 2020 11:30 pm
First Name: Mike
Last Name: Silbert
Location: Sykesville Md
MTFCA Life Member: YES

Re: Engine CAD files?

Post by Mike Silbert » Sun Nov 09, 2025 12:16 am

Try these links and see if they are what you want
https://grabcad.com/library/190-ford-model-t-engine

https://engineeringdl.com/project/ford- ... olidworks/

https://cults3d.com/en/search?q=model+t+ford

And I am sure there are more out there
Top
User avatar

DanTreace
Posts: 3966
Joined: Sun Jan 06, 2019 10:56 am
First Name: Dan
Last Name: Treace
* REQUIRED* Type and Year of Model Ts owned: '23 cutoff pickup, '27 touring
Location: North Central FL
Board Member Since: 2000
Contact:
Contact DanTreace

Re: Engine CAD files?

Post by DanTreace » Mon Nov 10, 2025 10:32 am

JBog wrote: ↑
Sat Nov 08, 2025 9:22 pm
 I like the idea of being able to have a little plastic engine that functions a little bit for demonstration purposes.

So did I, a forum thread began in 2011 about a model T engine model, was really neat.....but the mfg didn't ever bring them to market, checking recently the original company is now out of business. Don't know if any were really made. :cry:
Image 11-9-25 at 8.28 PM.jpeg
The best way is always the simplest. The attics of the world are cluttered up with complicated failures. Henry Ford
Don’t find fault, find a remedy; anybody can complain. Henry Ford
